Long-Range Ultrasound Device V3000-L4000
The V3000-L4000 is a long-range ultrasound imaging device ideal for inspecting large or complex structures. This advanced system offers deep penetration for effective imaging in thick materials and challenging environments. With enhanced signal processing and high durability, the device is suitable for harsh industrial conditions.
Long-Range Ultrasound Device V3000-L4000
The V3000-L4000 is a long-range ultrasound imaging device ideal for inspecting large or complex structures. This advanced system offers deep penetration for effective imaging in thick materials and challenging environments. With enhanced signal processing and high durability, the device is suitable for harsh industrial conditions.
Selection Parameters
| Parameters | Min | Max |
|---|---|---|
| Scanning Range X×Y,X×θ(mm,°) | 4000×2000,3920×360° | |
| Frequency(MHz) | 1~30 | |
| Amplification(dB) | 80 | |
| Applicable Probes(MHz) | 5,10,15 | |
| Water Circulator(option) | Available | |
| UPS(option) | Available | |
| Power supply | AC200~220V,50/60Hz 20A | |
| Body External Dimensions(W×D×H:mm) | 5220×2700×1700 |
Machines / Applications
| Inspection of large pipelines |
| Structural integrity assessment in heavy industries |
| Monitoring of large-scale industrial equipment |
| Inspection of storage tanks and pressure vessels |
Industries
| Oil & Gas |
| Petrochemical |
| Power Generation |
| Heavy Equipment Manufacturing |
