Ultrasound Imaging Device V3000W
The V3000W ultrasound imaging device is designed for high-resolution inspection across various industrial applications. With advanced imaging technology, this device ensures precise flaw detection and material evaluation. The lightweight and compact design makes it ideal for portable operations, while the user-friendly interface allows for quick setup and seamless data interpretation.
Ultrasound Imaging Device V3000W
The V3000W ultrasound imaging device is designed for high-resolution inspection across various industrial applications. With advanced imaging technology, this device ensures precise flaw detection and material evaluation. The lightweight and compact design makes it ideal for portable operations, while the user-friendly interface allows for quick setup and seamless data interpretation.
Selection Parameters
| Parameters | Min | Max |
|---|---|---|
| Wafer size(X*Y) | 12 | |
| Scan speed(mm/s) | 1200 | |
| Resolution(mm) | 0.001 | |
| Power supply | AC200~220V,20A | |
| Body size(W×D×H) | 1500×1480×1550(mm) | |
| Weight(kg) | 850(kg) | |
| Interlock | Emergency button,Door sensor. | |
| Inspect mode | C-scan,Program-scan,Warpage-scan,Index-scan,Full waveform scan. | |
| Analyze method | Defect area measurement,Defect position measurement,Color thresholding,Waveform analyze,Image process by FFT. | |
| Options | Water filter unit,Ultrasonic sensor(5~150MHz),Sensor Adapter. |
Machines / Applications
| Non-destructive testing (NDT) in manufacturing |
| Material thickness measurement |
| Flaw detection in metals, plastics, and composites |
| Weld inspection and quality control |
Industries
| Aerospace |
| Automotive |
| Shipbuilding |
| Construction |
| Energy and utilities |
